Taken from working unit.
The EK1100 EtherCAT Coupler is the link between the EtherCATprotocol at fieldbus level and the EtherCAT Terminals. The coupler converts thepassing telegrams from Ethernet 100BASE-TX to E-bus signal representation. Astation consists of a coupler and any number of EtherCAT Terminals that areautomatically detected and individually displayed in the process image.
Special features:
Connection technology: 2 x RJ45 socket
Connection lengths: up to 100 m
Number of EtherCAT Terminals in the overall system: up to65,535
The EK1100 has two RJ45 sockets. The upper Ethernetinterface is used to connect the coupler to the network; the lower socketserves for the optional connection of further EtherCAT devices in the samesegment. In addition, an EtherCAT junction or an EtherCAT extension can be usedfor the extension or for setting up a line or star topology.
The system and field supply, each 24 V DC, is provideddirectly at the coupler. The attached EtherCAT Terminals are supplied with thecurrent required for communication from the supplied system voltage. Thecoupler can supply a maximum of 5 V and 2 A. If higher current is required,power feed terminals such as the EL9410 have to be integrated. The field supplyis forwarded to the individual I/O components via the power contacts with up to10 A.
In the EtherCAT network, the EK1100 can be installedanywhere in the Ethernet signal transfer section (100BASE-TX) – except directlyat the switch. The EK9000 and EK1000 couplers are suitable for use at theswitch.
