• Stroke 10 mm
• Piston diameter 16 mm
• Spring return force with retracted piston rod 5 N
• Cushioning Elastic cushioning rings/plates at both ends
• Mounting position optional
• Mode of operation Pushing Single-acting
• Design Piston Piston rod
• Position detection Without
• Symbol 00991730
• Operating pressure 0.15 MPa … 1 MPa
• Operating pressure 1.5 bar … 10 bar
• Operating pressure 21.75 psi … 145 psi
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
• Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
• Corrosion resistance class CRC 1 – Low corrosion stress
• LABS (PWIS) conformity VDMA24364-B1/B2-L
• Ambient temperature -20 °C … 80 °C
• Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 112 N
• Moving mass 11 g
• Product weight 47 g
• Type of mounting Either: With through-hole With accessories
• Pneumatic connection M5
• Note on materials RoHS-compliant
• Material cover Wrought aluminium alloy Anodised
• Material seals NBR TPE-U(PU)
• Material housing Wrought aluminium alloy Anodised
• Material piston rod High-alloy steel

Importantinformation:

Price(s) do not include VAT!: For more information, please scroll down to”Terms & Conditions”, section “Payment”.

Shipping: Please contact us for a specific shipping price.

Terms& Conditions

Thissale includes the equipment ONLY. No other parts or accessories will be included unless otherwise mentionedin the sales notification.

Payment

Fullpayment is due within 2 business days from sale unlessseparately agreed otherwise in advance.

Pleasenote that all prices are VAT (tax) excluded and EXW Estonian warehouse(EXW = Ex Works).

Incase you are:

– Aprivate purchaser / consumer inside EU, please note that VAT (tax) will be addedto the total price. Tax rate (%) is 24%

– Abusiness buyer inside EU (except Estonian companies), please provide us yourvalid VAT number and the price stays the same (no VAT added)

-Outside European Community VAT is not applied
