🔧 Technical Overview

• Type : SPDT (Single-Pole, Double-Throw) coaxial switch

• Frequency Range : DC – 18 GHz, 50 Ω impedance

• Control Voltage : 12 V DC

📉 RF Performance

• Isolation : ≥ 60 dB

• Insertion Loss : ≤ 0.5 dB (at 18 GHz) VSWR : up to 1.5:1

⚙️ Mechanical & Operational Features

• Actuation : Fail-safe coil mechanism with built-in indicator LED Terminal Type : Solder-pin mounting; uses SMA coaxial ports

• Rating :

• • Contact life: ~5 × 10⁶ cycles (electrical & mechanical)

  • Can handle up to ~120 W (at 3 GHz), rated coil power ~840 mW

  • Temperature Range : –55 °C to +85 °C
